Outlets with Bulkhead V1
Product description
Connectors for modern industrial applications need to be designed in such a way that they simplify processes and cope with faster data transmission. Telegärtner recommends the connectors of Variant 1 for generic cabling of factory automation machinery (Automation Island, ODVA) acc. IEC 61918 Ed.1.0 in a robust metal or plastic design. The connectors of Variant 1 are standardized in the IEC 61076-3-106, designed to meet the demands of harsh industrial environments, guaranteeing protection class IP67 whether mated or unmated (using the IP67 protection cap). Furthermore, the modular principle - which is used on all connectors with STEADYTEC®-Technology - allows us to offer a wide range of products. Benefit from maximum flexibility and choose the insert you need! The RJ45 plug and bulkhead inserts stand out due to high power reserves and offer transmission characteristics of category 6A acc. to ANSI/TIA/EIA 568B.2-10. The FO plug and bulkhead inserts are available for GOF and POF-fibres and provide the most suitable solution for every application.
The specification of an Automation Outlet (TO) is based on IEC 61918 Ed.1.0. It is one of the functional elements of a generic cabling for factory automation machinery in areas subject to extreme ambient stresses due to temperature, dust, moisture or splashing water. For this purpose Telegärtner offers industrial outlets with mounted bulkheads of Variant 1. They are used to connect devices or complete automation islands. The unbreakable, powder-coated housings in RAL 7001 are available as single- or double gang versions in protection class IP67, allowing installation direct in manufacturing environments. The outlets are available with a cable entry from the top or rightwards.
Performance Characteristics
Variant 1 acc. to IEC 61076-3-106
protection class IP67
available with RJ45 Cat.6A, USB or FO insert
rugged zinc diecast or plastic housing
storage of cables with diameter 5...10 mm
pre-assembled plugs and set products for simple assembly
simple mounting of bulkheads through a central screwed gland or four screws
with bend protection to prevent cables from being excessively bent
NBR aiguilette at the protection cap
colour codings available
bay for marking labels
Mechanical Characteristics
Material: housing: aluminium, grey coated
Material: screws to fix the cover of housing: Stainless steel
Material: gaskets: CR, black
Material: ground connection: Stainless steel
Material: cable gland: brass, PA
Standards
Connectors: IEC 61076-3-106
Degrees of protection provided by enclosures (IP code): IEC 60529
Telegartner: STX V1 surface mounting outlet
Telegartner: STX V1 surface mounting outlet,
plastic, RJ45 module P Cat.6A, with protection cap, IP67
Price on request
Telegartner: STX V1 free coupling outlet
Telegartner: STX V1 free coupling outlet,
plastic, RJ45 module P Cat.6A, with protection cap, IP67
Price on request
Telegartner: STX V1 free coupling outlet
Telegartner: STX V1 free coupling outlet,
plastic, RJ45 module B Cat.6A, with protection cap, IP67
Price on request
Telegartner: STX V1 free coupling outlet
Telegartner: STX V1 free coupling outlet,
plastic, RJ45 module A Cat.6A, with protection cap, IP67
Price on request
Telegartner: STX V1 Surface mount housing
Telegartner: STX V1 Surface mount housing,
single gang, vertical cable feed, metal housing, IP67, LxWxH = 75x80x57
Price on request
Telegartner: STX V1 Surface mount housing
Telegartner: STX V1 Surface mount housing,
double gang, vertical cable feed, metal housing, IP67, LxWxH = 125x80x57
Price on request
Telegartner: STX V1 Surface mount housing
Telegartner: STX V1 Surface mount housing,
double gang, right hand cable feed, metal housing, IP67, LxWxH = 125x80x57
Price on request
Telegartner: STX V1 surface mounting outlet
Telegartner: STX V1 surface mounting outlet,
plastic, RJ45 module B Cat.6A, with protection cap, IP67
Price on request
Telegartner: STX V1 surface mounting outlet
Telegartner: STX V1 surface mounting outlet,
plastic, RJ45 module A Cat.6A, with protection cap, IP67
Price on request
